YT- LW Automatic High Speed Pa per Plate Forming Machine is developed and researched for the market requirement.it has integrated the pneumatic and mechanic technologies,which makes it higher speed,safer operation and easier maintenance from the conventional one.it is the first-Class product in technology from home and abroad.
1. Adopts high efficent pressure cylinder,the max pressure is up t0 5T.Compared with oil pressure,it has advantages of high speed,environment pro- tection,and humanism design.
The technical parameter for the cylinder a re described as follows. A. MPT-80-200-5T-15 B. Air flow volume:0.3m3/min C. Air pressure:0.55-0.5Mpa D. Air cylinder stroke:200mm
2. Widely applied to produce paper plate or aluminium foil plate.round or square plate with different size and shapes.
|
机型
|
YT-LW
|
|
纸杯规格
|
5-12inch（the mould is adjustable）
|
|
杯纸原料
|
100-1000g/gsm paper,Al.paper,paper board
|
|
定额生产率
|
65-80只/分钟（一个工体）
|
|
电源
|
220V 50Hz
|
|
总功率
|
3kw
|
|
重量
|
500KG
|
|
尺寸（长×宽×高）
|
1420×1200×1900mm
|
